   semi automatic Sliding DOOR mechanism Description:

Relate automatic sliding door operator:

Model: VZ-125

             VZ-155
             VZ-195
             VZ-ES200

FOB PRICE: 130-165 USD

WARRANTY: 24 Months

TEL:+8618971265826

Semi automatic sliding door

WhatsApp:+8618971265826

The Semi Automatic Sliding Doors System is a sliding door which is opened manually but closes automatically with the help of an cylinder mechanism. It does not require any electrical power connection. Another feature of this door is that it closes softly on the last end making its closing very smooth and silent. The closing speed can be adjusted as per the traffic movement and opening size. The maximum single door width possible for this system can be 1200mm and the maximum single door weight 100kg. The door can be integrated with standard locks. An ideal application for these doors is rest room entrances, conference rooms, hotels, offices and partitions etc. The system can be used for frameless glass doors as well as framed wooden doors.

tel no.
whatsapp

   SEMI-AUTOMATIC DOOR SYSTEMS PARAMETERS:

Send an inquiry

   SEMI-AUTO DOOR CLOSER PROJECTS:

ModelDSMS-22DSMS-31DSMS-44A
DSMS-44B
Door weight
10-80kgs/leaf
30-100kgs/leaf
10-60kgs/leaf
20-80kgs/leaf
Door width
700-1200mm
1200-1600mm
700-1200mm
700-1200mm
Spring thickness
0.265mm
0.385mm
0.265mm
0.385mm
2200mm
2200mm
3100mm
4400mm
4400mm


Skype:autodoorleader

Semi automatic sliding door mechanism

SHIPPING: Worldwide by sea or by                    express delivery

skype
Semi-automatic sliding door closer

– Sliding door opened manually, and then closed automatically
– No motor, no drive device, energy saving
– No door rail on a floor, so easy going in and out with bed and wheel chair
– Smooth and silent operation
– Adjustable operation speed
– Safe closing by damper brake system
– Easy assembling of the parts and easy changing of open direction of doors
– Any time Keep closing(as applicable, keep opening function)
– Suitable for frameless glass doors(10-12mm), or wooden doors.
– Suitable for hotels, offices and partitions.

Semi automatic sliding door mechanism

LEAD TIME: 2-5 Days

MODEL: Semi-automatic sliding doors

PORT: Shanghai or Ningbo etc.

You are here:Home > Semi automatic sliding door mechanism

   SEMI AUTO SLIDING DOOR OPERATOR FEATURES:
